| CPU | AMD Socket AM4, support for: AMD Ryzen™ 5000 / 5000 G / 4000 G / 3000 & 3000 G-Series Processors
(Refer to "CPU Support List") |
| Chipset | AMD A520 |
| Memory | 4 x DDR4 DIMM sockets, up to 128 GB (32 GB per DIMM)
Ryzen 5000 G / 5000 / 3rd Gen Ryzen: DDR4 4400(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz
3rd Gen Ryzen with Radeon Graphics: DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz
Dual channel architecture, ECC & non-ECC support, XMP supported |
| Onboard Graphics | 1 x DVI-D (max 1920x1200@60Hz)
1 x DisplayPort (max 5120x2880@60Hz, DP1.4, HDCP2.3, HDR)
1 x HDMI (max 4096x2160@60Hz, HDMI2.1, HDCP2.3, HDR)
Support for up to 3 displays, Maximum shared memory 16 GB |
| Audio | Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel
*7.1-channel requires software configuration |
| LAN | Realtek® GbE LAN (1 Gbps / 100 Mbps) |
| Wireless Communication Module | Intel® Dual Band Wireless-AC 3168 (PCB rev. 1.0/1.2/1.3), 802.11a/b/g/n/ac 2.4/5 GHz, Bluetooth 4.2
Intel® Wireless-AC 9260 (PCB rev. 1.1), 802.11a/b/g/n/ac 2.4/5 GHz, Bluetooth 5.1, 11ac 160MHz
AzureWave Wi-Fi AW-CB304NF (PCB rev. 1.4), 802.11a/b/g/n/ac 2.4/5 GHz, Bluetooth 5.0 |
| Expansion Slots | CPU: 1 x PCIe x16 (PCIe3.0, x16)
Chipset: 2 x PCIe x1 (PCIEX1_1, PCIEX1_2) |
| Storage Interface | CPU: 1 x M.2 Socket 3 (2242/2260/2280 SATA & PCIe3.0 x4/x2)
Chipset: 4 x SATA 6Gb/s, RAID 0/1/10 supported |
| USB | CPU: 4 x USB 3.2 Gen1 (back panel)
Chipset: 2 x USB 3.2 Gen1 (internal), 4 x USB 2.0/1.1 (2 back, 2 internal) |
| Internal I/O Connectors | 1 x 24-pin ATX main power
1 x 8-pin ATX 12V
1 x CPU fan header, 2 x system fan headers
1 x addressable LED header, 1 x RGB LED header
1 x M.2 Socket 3, 4 x SATA 6Gb/s
1 x front panel, 1 x front panel audio
1 x USB 3.2 Gen1 header, 1 x USB 2.0/1.1 header
1 x TPM header (2x6 pin)
1 x serial port header, 1 x Clear CMOS jumper
1 x Q-Flash Plus button
*All fan headers support AIO_Pump/Pump/high-performance fans (up to 2A/12V @24W) |
| Back Panel Connectors | 1 x PS/2 keyboard/mouse
1 x DVI-D, 1 x DisplayPort, 1 x HDMI
2 x SMA antenna connectors (1T1R)
4 x USB 3.2 Gen1, 2 x USB 2.0/1.1
1 x RJ-45
3 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage, Temperature, Fan speed, Overheating & Fan fail warnings, Fan speed control* (*depends on cooler installed) |
| BIOS | 1 x 128 Mbit flash, AMI UEFI BIOS, PnP1.0a, DMI2.7, WfM2.0, SMBIOS2.7, ACPI5.0 |
| Unique Features | APP Center*, @BIOS, EasyTune, RGB Fusion, Smart Backup, System Information Viewer, Q-Flash Plus, Q-Flash
*Application support may vary by model |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System | Windows 11 64-bit, Windows 10 64-bit |
| Form Factor | Micro ATX; 24.4cm x 24.4cm |
