Hardware Specifications

Antenna

Antenna

• 4 x external antennas

Antenna gain (2.4 GHz)

• 4 dBi

Antenna gain (5 GHz)

• 5.5 dBi

Wi-Fi Radio

FEM

• iPA

Max. Wi-Fi Speed

• 2.4 GHz, 400 Mbps
  5 GHz, 867 Mbps

Wi-Fi standard

• Wi-Fi 5 (IEEE 802.11ac)

Software Specifications

Network Management and Monitoring

Ruijie Cloud management

• Yes

Reyee Mesh 3.0

Reyee Mesh 3.0

• Yes

System Performance Capacity

Maximum number of concurrent clients

• 32 (2.4 GHz)
  64 (5 GHz)

Recommended number of concurrent clients

• 8 (2.4 GHz)
  24 (5 GHz)

IP Service

IPv6

• Yes
